VIPRION LEDs and Interfaces
Platform Guide: VIPRION
®
4 - 9
Table 4.10 defines the behavior for XFP optic interfaces.
Table 4.11 defines the behavior for SFP+ optic interfaces.
Speed LED Activity LED Link Blade type
Not lit Not lit No link PB100
Solid green Green (with traffic) 10Gbps, full duplex PB100
Table 4.10 XFP optic interface LEDs
Speed LED Activity LED Link Blade type
Not lit Not lit No link PB200
Not supported Not supported 10Mbps, half duplex PB200
Not supported Not supported 10Mbps, full duplex PB200
Not supported Not supported 100Mbps, half duplex PB200
Not supported Not supported 100Mbps, full duplex PB200
Not supported Not supported 1000Mbps, half duplex PB200
Solid yellow Green (with traffic) 1000Mbps, full duplex PB200
Not supported Not supported 10Gbps, half duplex PB200
Solid green Green (with traffic) 10Gbps, full duplex PB200
Table 4.11 SFP+ optic interface LEDs
