Indicator LED actions
The behavior, or action, of each of LED indicates the status of the system.
Standard operating states
When the platform is in a standard operating state, the LEDs behave in a
defined manner. On power up, the status LED of each blade turns yellow.
When the BIG-IP
®
software successfully boots, the status changes to green.
Action Description
Off (none) The LED is not lit and does not display any color.
Solid The LED is lit and does not blink.
Blinking The LED turns on and off at a regular frequency.
Intermittent The LED turns on and off with an irregular frequency
and may sometimes appear solid.
Table 4.3 Indicator LED actions
System State Alarm LED Status LED
Power is off off/none off/none
Active mode off/none green solid
Table 4.4 Standard operating states of the LEDs on the VIPRION chassis
Blade State Alarm LED Status LED
Power is off off/none off/none
Secondary off/none green solid
Primary off/none green solid
Table 4.5 Standard operating states of the LEDs on blades
