ENGLISH
4.3A ADJUSTING THE COUNTER-THRUST WHEEL
Thecarriageshaveacounter-thrustwheelwhichpreventsthem
fromcomingoutoftheirseat.
The wheel must be adjusted so that it does not press on
the support profile, to thus avoid increased friction.
Counter-thrustwheeladjustmentprocedure:
• LoosenthescrewM6(Fig.30ref.1).
•
Adjust the height of the wheel support, making it come
ascloseaspossibletothemainprofilewithouttouchingit
(Fig.30ref.2).
•
Whenyouhaveadjustedthewheel’sheight,tightenthescrew
M6(Fig.30ref.a).
Ifnecessary,useashimofabout0.5mm,placingitbetweenthe
wheelandthemainprofile,removingitwhenyouhavefinished
theadjustment.
Movetheleavesbyhandandcheckifthecounter-thrustwheel
isfreetomovewithoutgrazing.
6 REGOLAZIONE ARRESTI MECCANICI 5A ADJUSTING THE OPENING MECHANICAL STOPS
Theautomatic dooris supplied withthe openingmechanical
stopsinstalledonthesupportprofile.Astheleavesopen,make
surethatthecarriagescomeintocontactwiththemechanical
stops.Ifadjustmentsarerequired,proceedasfollow:
• LoosentheAllenscrewsofthemechanicalstops(Fig.31ref.
a)andtakethemtotheendsofthesupportprofile.
• Taketheleaforleavesintoopeningposition(fig.32),take
themechanicalstopneartothecarriageuntilthetwoparts
touchandtightenthe
Allenscrews(Fig32ref.a).
fig. 30
fig. 32
fig. 31
