ENGLISH
Double leaf automated systems:
InstallbrushesasshowninFig.34ref.A.
Single leaf automated systems:
Fitthebrushesasindicatedinfig.34ref.B
7A INSTALLING BRUSHES
Transit space
Transit space
Transit space
LH opening single leaf
RH opening single leaf
brush
brush
brush
brushes
Double leaf
fig.34
