FAAC A140 AIR - Obstacle Detection

55
ENGLISH
Opening: Standard
If an obstacle is detected during opening, the door stops for one
second and then re-closes.
Opening: No Standard
If an obstacle is detected for 3 consecutive times at opening,
the door stops in closed position, and causes an alarm signal
onthecontrolboardandonSD-Keeper(alarmNo.8-obstacle
during opening ).
To restore operation, resetting is necessary either from the control
boardorfromSD-Keeper.
3 BATTERY
3.1 Battery kit
Off
Battery kit not installed.
On
Battery kit installed.
3.2 Bat. operation
Standard
If there is a power cut and the operating function is other than
“Night”, the door continues operating normally until the battery
has sufficient charge reserve to perform at least one emergency
movement.
The last movement operation to be executed is the one selected
with function 3.3.
No Standard
In the event of a power cut, the door executes only the moving
operation selected with function 3.3.
3.3 Last operat.
Opening
Duringbatteryoperatedfunctioning,thelastmovingoperation
is opening (see also function 3.2).
Closing
Duringbatteryoperatedfunctioning,thelastmovingoperation
is closing (see also function 3.2).
3.4 Night batt.
Not available in the A140 AIR 140 automated
system.
4 LOCK
4.1 Kit lock
On
Motorlockinstalled.
Night
The motor lock locks the leaves only in the “night” operational
function.
One way+Night
The motor lock locks the leaves in the “night” and “one way”
operational functions.
Always
The motor lock locks the leaves whenever they close, irrespective
of the set operational function.
1 LANGUAGE
Selects the language for showing the messages on the display.
2 SETUP
2.1 Partial opening
Partial opening percentage
Selects the opening percentage (referred to total opening)
performed in the “partial opening” operational function.
Standard value: 50%
Adjusting range: from 10% to 90%
Standard
When the “partial opening” operational function is selected,
sensor activation always causes a partial opening command.
No Standard
When the “partial opening” operational function is selected,
simultaneous activation of the internal and external sensors
commands total opening.
2.2 Pause time
On
Pause time enabled in the “automatic” operational function.
Pause time value
If pause time is enabled, it can be set.
Standard value: 2 sec.
Adjusting range: from 0 to 30 sec. in 1 sec. steps
Off
Pause time is disabled and the leaves begin to close as soon as
the command elements (e.g.sensors) become inactive.
2.3 Night pause time
Night pause time value
It sets pause time in the “night” operating function when a
command is given on the KEY input.
Standardvalue:8sec.
Adjusting range: from 2 to 240 sec in steps of 2.
2.4 Anti intruder
On
In “Automatic” operating mode, the door opposes manual
opening attempts by means of contrary force.
Duringtheattempttoopen,analarmissignalledonthecontrol
boardandontheSD-Keeper(alarm#3-forceddoor).
With the door closed, the board continues powering the motor
during closing, except when the automated system operates on
the battery while the motor is locked.
Off
In “automatic” operating mode, when manual opening is
attempted, the door opens automatically and re-closes after
any pause time.
In the “night” operational function, the anti-intruder
is always active.
2.5 Obstacle detection
Closing: Standard
If an obstacle is detected during closing, the door re-opens.
Closing: No Standard
If an obstacle is detected for 3 consecutive times at closing,
the door stops in open position, and causes an alarm signal
onthecontrolboardandonSD-Keeper(alarmNo.9-obstacle
during closing).
To restore operation, resetting is necessary either from the control
boardorfromSD-Keeper.
