38
ENGLISH
SETUP
The following parameters are checked and adjusted during
the Setup cycle:
• measurement of masses and friction, setting of speeds, plus
optimal acceleration and deceleration;
• acquisition of open and closed door positions;
• self-setting of the anti-crushing system at opening/closing
according to selected speeds.
DuringSetup,onthedisplayflashesstatus08untiltheendofthe
process if correctly executed.
Any faults are signalled by the display and by the diagnostics
viaSD-Keeper.
Detectionofseriousfaults(e.g.insufficientorexcessiveleaftravel,
too much friction, motor malfunctions) is signalled by the display
andbythediagnosticsviaSD-Keeper.
To activate a new Setup procedure, press and release the SW1
push-button on the board for more than 5 seconds and then
release it; Setup can also be started by a combination of push-
buttonsonSD-Keeper(seerelevantinstructions).
The following are the situations in which, if required, the Setup
cycle is not executed, and the door stays in shut-down state,
generatinganalarmsignal(ALARM15onthedisplayand on
SD-Keeper):
• door powered by battery;
• NIGHToperatingfunctionselected;
• MANUALoperatingfunctionselected;
• an emergency input is active;
• photocells engaged;
• no power supplied to motor.
• external or internal release activated
When the cause has been eliminated, the Setup starts
automatically.
RESET
Whenever the automated system is powered, the door executes
a Reset cycle during which:
• the door’s travel limit positions are sought;
• any alarm signals are reset.
To activate a new Reset procedure, press the SW1 push-button
on the board for 1 second; Reset can also be started by a
combination of push-buttons on SD-Keeper(see relevant
instructions).
IfaResetiscommandedwhilethedoorisin“Manual”mode,it
is executed when this operating function is exited.
In the “Night” operating function, Reset consists of a slow closing
movement, whereas it is normally a slow opening movement.
The reset procedure is necessary following the occurrence of
certain conditions causing the door to stop operating:
• after an obstacle is detected on 3 successive occasions
during closing/opening when the function NO STANDARD
OBSTACLE DETECTION (ALARM 8 or ALARM 9) has been
activated;
• after a “with memory”-configured emergency command
hasbeenactivated(seeprogramminginstructions),(ALARM
6orALARM7);
• if, when using a motor lock kit, an opening malfunction is
detected on the kit.
