BEISSBARTH MT 740/ 745, 741/ 746
4-6
adjustable bolts and double-ended conical nuts or quick-
clamping cones:
Open the flange as far as possible by twisting the rear
cam plate against the front guide pulley and insert the
required threaded bolts into the numbered guides.
Synchronous adjustment of hole circles takes place when
the cams are twisted. The circles can be read off at a dial
mounted to the end face.
Mount the wheel on to the flange as described under Item 9
(see Figure 10).
Fig. 10
Motorcycle Pro Bike flange
For all motorcycle wheels from 2” rim width with a centre bores from 14mm to 25mm (with special
accessories also for centre bores from 10- and 12 mm).
12. Centring of wheel with centring sleeves or centring cones
and mounting with knurled nut.
The two sprung driving-plate pin tighten and push the
wheels running surface from outside.
Put a accuracy in fitting centring sleeve in the wheel hub
and mount them on the outer wheels running surface.
Make sure that the wheel rests on the centring sleeve
shoulder, and not against the driving plate. If necessary,
fit intermediate spacing sleeve. Insert second centring
sleeve over centre shaft into wheel hub and secure wheel
with large knurled nut.
For special wheel hubs, use the two centring cones
instead of the centring sleeves.
Fig. 11
