WASHING THE SOLUBLES CIRCUIT (WHERE PRESENT)
The following indications are for machines with a soluble
products selection and performed in addition to the washing
procedure described above.
MIXER CLEANING
1 powder funnel
2 powder storage drawer
3 mixer conveyor
4 mixer blade
5 nozzle
1
3
4
2
5
S
B
A
1
Open the lock (A) to access the solubles
mixer
2
Open the control panel (B).
3
1
Detach the powder funnel (1).
4
Remove the nozzle (5) from the mixer
conveyor (3).
5
Turn the ringnut (G) clockwise.
6
Remove the mixer conveyor (3).
3
5
G
3
4
2
7
Remove the mixer blade (4).
8
Remove the powder storage drawer (2).
9
Disassemble the delivery spout and
rimove the silicon pipe (S).
Here are the steps to perform at the end of the work day.
Please follow these steps:
64
