Fagor 9CFB61 - Assembling the Ventilation Shaft

26
2 / INSTALLING YOUR APPLIANCEEN
• ASSEMBLING THE VENTILATION
SHAFT
• Outdoor evacuation
— Calculate the  nal height for  xing the
duct support U-bracket (part B Pic. 1)
— Mark the two holes accordingly
— Drill 8 mm diameter holes and secure
the duct support bracket, ensuring that it is
 xed on the same axis as the hood (part B
Pic. 1)
— Fix the  at bracket behind the lower
duct.
— Fix the two ducts to the hood.(Pic. 5)
— Connect the sleeve to the air outlet to the
outside.
— Make the electrical connection to the
hood using the mains supply cable.
— Lift the upper duct up to the ceiling and
 x it to the bracket using the screws.
Pict 6
Pict 5
Pict 4
Pict 3
