N
EW
F
EATURES
(S
OFT
M: 7.
XX
)
Page 29 of 50
CNC 8055 / CNC 8055i
Oscilloscope
function
CNC variables that may be assigned to a channel
Examples: ANAI1, FREAL, FLWEX, FREALZ
Fagor Sercos Drive variables that may be assigned to a channel
Indicate the desired axis and variable, separated by a period.
Examples: X.CV3, Y.SV1, S1.SV2
Trigger conditions
Channel
Indicates which variable or channel (CH1, CH2, CH3, CH4) is to be
used as a reference or trigger condition.
Trigger
Indicates the beginning of the data capture.
If not selected, the data capture begins as soon as the operator
gives the go ahead. The Flank, Level and Position data are ignored.
If selected, specify the trigger condition using the Flank, Level and
Position data.
Flank
It is taken into account when Trigger has been selected. It may be
an up flank or a down flank.
Variable Characteristics
ANAI(1-8) Voltage of input 1-8
ANAO(1-8) Voltage to apply to output 1-8
FREAL CNC real feedrate
FREAL(X-C) Actual (real) X-C axis feedrate
FTEO(X-C) Theoretical X-C axis feedrate
FLWE(X-C) X-C axis following error
ASIN(X-C) "A" signal of the CNC sinusoidal feedback for the X-C axis
BSIN(X-C) "B" signal of the CNC sinusoidal feedback for the X-C axis
DRPO(X-C) Position indicated by the Sercos drive of the X-C axis
SREAL Real (actual) spindle turning speed.
FTEOS Theoretical spindle turning speed
FLWES Spindle following error
ASINS "A" signal of the CNC sinusoidal feedback for the spindle
BSINS "B" signal of the CNC sinusoidal feedback for the spindle
DRPOS Position indicated by the Sercos drive of the spindle
SSREAL Real (actual) second spindle turning speed.
SFTEOS Theoretical second spindle turning speed
SFLWES Second Spindle following error
SASINS "A" signal of the CNC sinusoidal feedback for the second
spindle
SBSINS "B" signal of the CNC sinusoidal feedback for the second
spindle
SDRPOS Position indicated by the Sercos drive of the second spindle
Variable Characteristics
CV3 CurrentFeedback
SV1 VelocityCommand
SV2 VelocityFeedback
SV7 VelocityCommandFinal
TV1 TorqueCommand
TV4 VelocityIntegralAction
RV1 FeedbackSine
RV2 FeedbackCosine
RV51 Feedback2Sine
RV52 Feedback2Cosine
