NEW FEATURES
(SOFT M: 9.0X)
CNC 8055 / CNC 8055i
Page 6 of 106
1.4 Hard disk diagnosis
From the diagnosis mode, it is possible to test the local or remote hard
disk. This operating mode is accessed from Diagnosis >Tests> Hard
disk.
Accessing this screen runs a test on the disk. Testing the hard disk
includes a test of the surface. This test is not carried out on a remote
hard disk and the relevant message is displayed.
When detecting an error, it shows the relevant error message at the
bottom of the window.
This mode shows the following information:
Physical information.
Hard disk model installed and information on the physical and logic
partition (cylinders, heads and sectors). The physical and logic
partitions might not be the same.
This information is only displayed for the local hard disk. When
having a remote hard disk, this information is not available.
Logic information.
Size in bytes of each of the blocks the disk is divided into. Total
number of blocks in the disk, free and occupied. Number of sectors
in a cluster.
The label is the name given to the disk when formatting it.
Mounting information.
If no error occurred, it shows the message "OK".
Local hard disk: In case of error, it indicates the error number and
the mounting stage where it came up.
Remote hard disk: In case of error, it only shows a message
indicating the type of error.
HARD DISK TEST
MOUNTING
LOGIC
Ok CAP INS
Block size
Total blocks
Free blocks
Occupied blocks
Sector/Cluster
Label
62846
40150
22696
8
BCB
4096
Bytes
Ok
PHYSICAL
Physical 984 16/ 32
Logic 984 16/ 32
Model * * *
P...... N....DIAGNOSIS 12:24:55DNC
