Drive modules
188
3.
DRIVE MODULES
Modular drives
142
DDS
HARDWARE
Ref.1310
Analog outputs Associated with pins 8-9 and 10-11. These outputs provide an analog volt-
age indicating the status of the internal system variables. They are espe-
cially designed as permanent monitoring of these internal variables and
also to be connected to an oscilloscope to make it easier to set the sys-
tem up.
Analog output
characteristics
INFORMATION. Note that
if the output current is high, the voltage range
may decrease.
Resolution 4.88 mV
Voltage range ±10 V DC
Maximum current ±15 mA
Impedance (respect to GND) 112
