Fagor DDS User Manual

Cables
CABLES
Motor feedback cables
7.
251
DDS
HARDWARE
Ref.1310
7.3 Motor feedback cables
The attached tables show the range of motor encoder cables supplied by
FAGOR to connect the motor feedback and a drive. They are supplied
with connectors at both ends (see note below) and their sales reference
is:
EEC-SP- cable
For further detail on how to connect the drive, see the manual of the cor-
responding motor.
IECD- cable
For further detail on how to connect the drive, see the manual of the cor-
responding motor.
EEC-FM7- cable
For further detail on how to connect the drive, see the manual of the cor-
responding motor.
EEC-FM7S- cable
For further detail on how to connect the drive, see the manual of the cor-
responding motor.
Motor Ref. Cable Motor feedback
FXM, FKM
EEC-SP-
 1 Vpp sinusoidal encoder
IECD-
 Incremental TTL encoder
FM7
EEC-FM7-
 Incremental TTL encoder
EEC-FM7S-

Incremental TTL encoder
(better immunity and flexibility)
EEC-FM7CS-
 C axis SinCos encoder
Note. None of the motor encoder feedback cables for FM7 spindle motors
will have the connector mounted at the motor end; a connector will be
supplied with the cable for the user to mount it. See the manual: AC spin-
dle motor - FM7/FM9 - for further detail on how to mount it.
INFORMATION. The encoder cable (without connectors) is only available
upon request in lengths of 75, 100 150 m.
i
T. H7/8 Range of EEC-SP- cables. The number indicates their length in
meters including the connectors.
EEC-SP- 5 EEC-SP-15 EEC-SP-25 EEC-SP-35 EEC-SP-45
EEC-SP-10 EEC-SP-20 EEC-SP-30 EEC-SP-40 EEC-SP-50
INFORMATION. Remember that using the cable reference EEC-SP-
does guarantee compliance with the Directive on Electromagnetic Com-
patibility (EMC).
i
T. H7/9 Range of IECD- cables.The number indicates their length in
meters including the connectors.
IECD- 5 IECD-10 IECD-15 IECD-20 IECD-25
T. H7/10 Range of EEC-FM7- cables. The number indicates their length
in meters including the connector.
EEC-FM7- 5 EEC-FM7-10 EEC-FM7-15 EEC-FM7-20 EEC-FM7-25
T. H7/11 Range of EEC-FM7S- cables. The number indicates their length
in meters including the connector.
EEC-FM7S-3 EEC-FM7S-15 EEC-FM7S-30 EEC-FM7S-45
EEC-FM7S-5 EEC-FM7S-20 EEC-FM7S-35 EEC-FM7S-50
EEC-FM7S-10 EEC-FM7S-25 EEC-FM7S-40
