3.1 Modular drives
When referring to modular drives, we will use AXD, SPD and MMC. They all admit a voltage range be-
tween 400 to 460 V AC. See all models in the following figures.
F. H3/1
Size-1 modular drives of the FAGOR catalog.
A. AXD/SPD 1.08/1.15, B. AXD/SPD 1.25, C. AXD/SPD 1.35, D. MMC 1.08/1.15, E. MMC 1.25, F. MMC 1.35
F. H3/2
Size-2 modular drives of the FAGOR catalog.
A. AXD/SPD 2.50/2.75, SPD 2.85, B. MMC 2.50/2.75.
