Fagor DDS User Manual

Drive modules
188
3.
DRIVE MODULES
Compact drives
146
DDS
HARDWARE
Ref.1310
Technical data
T. H3/14 Current in compact drives for synchronous motors. fc = 4 kHz.
With internal fan Drive for synchronous motor (as axis)
Currents at fc=4 kHz
(A)
ACD/CMC
1.08
ACD/CMC
1.15
ACD/CMC
1.25
ACD/CMC
2.35
ACD/CMC
2.50
Rated current (Arms) 4.0 7.5 12.5 17.5 25.0
(*)Maximum peak current for
500 ms in 10 s cycles.
8.0 15.0 25.0 35.0 50.0
Dissipated power (W) 40 87 110 160 222
T. H3/15 Current in compact drives for synchronous motors. fc = 8 kHz.
With internal fan Drive for synchronous motor (as axis)
Currents at fc=8 kHz
(A)
ACD/CMC
1.08
ACD/CMC
1.15
ACD/CMC
1.25
ACD/CMC
2.35
ACD/CMC
2.50
Rated current (Arms) 4.0 7.5 9.5 17.5 20.0
(*)Maximum peak current for
500 ms in 10 s cycles.
8.0 15.0 19.0 35.0 40.0
Dissipated power (W) 50 118 139 206 226
T. H3/16 Current in compact drives for synchronous or asynchronous motors. fc = 4 kHz.
With internal fan Drive for synchronous or asynchronous motor (as spindle)
Currents at fc=4 kHz
(A)
SCD
1.15
SCD
1.25
SCD
2.35
SCD
2.50
SCD
2.75
(*)
Maximum current in any duty cycle
(Arms).
10.6 17.5 28.0 38.0 52.0
Dissipated power (W) 123 150 215 275 395
* This current must be equal to or greater than that of the corresponding asynchronous motor in S6.
T. H3/17 Current in compact drives for synchronous or asynchronous motors. fc = 8 kHz.
With internal fan Drive for synchronous or asynchronous motor (as spindle)
Currents at fc=8 kHz
(A)
SCD
1.15
SCD
1.25
SCD
2.35
SCD
2.50
SCD
2.75
(*)
Maximum current in any duty cycle
(Arms).
10.6 12.5 19.5 27.0 39.0
Dissipated power (W) 123 150 220 315 410
* This current must be equal to or greater than that of the corresponding asynchronous motor in S6.
NOTE. The indicated dissipated power values for the spindles correspond to the operation at rated
current in S1 mode.
