Drive modules
DRIVE MODULES
Compact drives
3.
155
DDS
HARDWARE
Ref.1310
Connector layout
The connectors of each compact drive are described next as well as other
elements such as indicator lights, status display and so on that are on the
front panel of the unit.
Initially it shows each compact drive model and mentions all its connectors
and later on, it analyzes all of them one by one in a single section because
most of them are the same for all the models.
