SELECTING CRITERIA
Power supply selection
220
DDS
HARDWARE
Ref.1310
Calculation of the power required from the power supply by the asynchronous motors
FAGOR asynchronous spindle motor FM7
where:
T. H5/7 Power supply selection when using an FM7 asynchronous spindle motor with E01 and E02
releases.
P
m
Maximum power that the drive may demand from the power supply in each motor-drive
combination. It includes the power dissipated by the drive itself (in kW).
Asynchronous
spindle
motor
Power (kW)  (%)
Drive
power
Drive for
asynchronous
spindle motor
Drive
Pm
S1 S6-40 S1 S6-40 (kW)
(%)
(kW)
FM7-A037 3.7 5.5 83.5 83.5 6.6 SPD 1.25 90 7.4
FM7-A055 5.5 7.7 86.0 84.5 9.1 SPD 1.25 90 10.1
FM7-A075 7.5 11.0 86.5 84.6 13.0 SPD 1.35 90 14.4
FM7-A090 9.0 13.0 87.3 85.7 15.2 SPD 2.50 90 16.9
FM7-A110 11.0 15.5 90.2 89.2 17.4 SPD 2.50 90 19.3
FM7-A150 15.0 22.0 90.4 89.3 24.6 SPD 2.75 90 27.4
FM7-B120 12.0 18.5 91.0 90.4 20.5 SPD 2.75 90 22.7
FM7-A185 18.5 26.0 91.8 91.5 28.4 SPD 2.85 90 31.6
FM7-A220 22.0 33.0 89.2 88.1 37.5 SPD 3.100 90 41.6
FM7-B170 17.0 25.0 89.1 87.7 28.5 SPD 2.85 90 31.7
FM7-A300 30.0 45.0 92.1 91.6 49.1 SPD 3.150 90 54.6
FM7-A370 37.0 56.0 92.5 91.7 61.1 SPD 3.200 90 67.9
FM7-B220 22.0 33.0 91.3 90.5 36.5 SPD 3.100 90 40.5
FM7-B280 28.0 42.0 91.1 90.0 46.7 SPD 3.150 90 51.9
FM7-A510 51.0 71.0 92.8 92.2 77.0 SPD 3.200 90 85.6
FM7-C215 21.5 29.0 85.4 82.7 35.1 SPD 3.150 90 39.0
FM7-C270 27.0 37.0 86.6 83.9 44.1 SPD 3.200 90 49.0
FM7-E600 60.0 80.0 92.2 91.4 87.6 SPD 3.200 90 97.3
ASYNCHRONOUS FOR SPINDLE, FM7. Releases E01 & E02
Max. power consumed by the power supply (kW)
ASYNCHRONOUS
Asynchronous for spindle Pm
1
2
SUM OF POWER:
(kW)
2

Pm: Required power obtained for the asynchronous spindle drive in S6-
40 % cycles. This data includes the internal losses of the drive.
