Power line connection
246
6.
POWER LINE CONNECTION
Types of mains
244
DDS
HARDWARE
Ref.1310
TT type mains
Distribution diagram that has a point connected directly to ground.
The
conductive parts of the installation are conn
ected to this groun
d point in-
dependently f
rom the ground
electrode of
the power supp
ly system.
F
. H6/5
Installation diagram in a TT type mains.
DDS
L1
L2
L3
L1
L2
L3
DDS
FACTOR
Y LINE
TRANSFOR
MER
DIFFERENTIAL
BREAKER
MAINS
FILTER
A
DIFFERENTIAL
BREAKER
FACTORY LINE
TRANSFORMER
MAINS
FILTER
A
243
245
