SALES REFERENCES
References of asynchronous motors
368
DDS
HARDWARE
Ref.1310
12.2 References of asynchronous motors
Sales reference of the asynchronous motors, FM7.
F. H12/3
Sales reference of the asynchronous motors, FM7.
BASE SPEED
(SINGLE WINDING)
FAGOR M7 MOTOR
1500 REV/MIN
A
B
FM7-

-

- E0

500 REV/MIN
1000 REV/MIN
C
POWER
(S1 DUTY CYCLE).
Note. The kW for each model are obtained from multiplying the given
value by 0.1. E.g.. An FM7- B280 motor can supply up to 28 kW in the
S1 duty cycle.
A
037 - 055 - 075 - 090 - 110 - 150 - 185 - 220 - 300 - 370 - 510
B
120 - 170 - 220 - 280
C
215 - 270
FEEDBACK
STANDARD ENCODER
S
C
C AXIS ENCODER
MOUNTING
FLANGE
1
3
FOOT
5
FLANGE+FOOT
VIBRATION
DEGREE
V10
B
C
V5
D
V3
SHAFT
PLAINT SHAFT (NO KEYWAY)
0
1
KEYWAY
(HALF-KEY BALANCING)
RELEASE
1
2
E01 SERIES
E02 SERIES
1250 REV/MIN E
E
600
(see note 1)
(see note 3)
(see note 3)
(see note 2)
BASE SPEED
(option to configure the winding connection)
FAGOR M7 MOTOR
D
FM7-

-

-

3
POWER
(S1 DUTY CYCLE).
Note. The kW for each model are obtained from multiplying the given
value by 0.1. E.g. An FM7- D150 motor can supply up to 15 kW in the
S1 duty cycle.
D
055 - 075 - 110 - 150 - 185 - 220
FEEDBACK
MAGNETIC TTL ENCODER
S
RELEASE
E0
HS
E03 SERIES
HS3 SERIE (hollow shaft)
1500 rev/min - star connection -
1000 rev/min - triangle connection -
MOUNTING
FLANGE
1
VIBRATION
DEGREE
V3
D
SHAFT
PLAINT SHAFT (NO KEYWAY)
0
NOTE 1. The "flange + foot" mount type comes in all models except
A037, A055, A075 and A090.
NOTE 2. Models A300, A370, B220,
B280 and E600 are not available for the E02 series.
NOTE 3. E600
models can only have the C axis option for feedback and V10 vibra-
tion degree.
NOTE 4. The FM7-D055 and FM7-D150 models will not be available in
the HS3 series.
