12.4 References of compact drives
Sales reference of the compact drives for synchronous axis servo mo-
tors, ACD.
Sales reference of the compact drives for synchronous or asynchronous
spindle motors, SCD.
F. H12/6
Sales reference of the ACD compact drive.
F. H12/7
Sales reference of the SCD compact drive.
Example:
A
XIS
C
OMPACT
D
RIVE
INTERFACE
ACD 2 . 50 - C0 - 2 - B
0
None
1
Encoder simulator
2
Direct feedback
Analog I/O
A1
SERCOSS0
SERCOS and Analog I/OSI
1
77 mm (08/15/25)
2
177 mm (35/50)
ADDITIONAL
FEEDBACK
FEATURES
B
CAPMOTOR-2
MOTOR
FEEDBACK BOARD
None
CAPMOTOR-1
Examples:
ACD 1.25-C0-2-A
Compact axis drive, size 1, with a peak current of 25 A at 4 kHz, with CAN board,
with Direct feedback board and with CAPMOTOR-1 motor feedback board.
ACD 1.25-C0-2-B
Compact axis drive, size 1, with a peak current of 25 A at 4 kHz, with CAN board,
with Direct feedback board and with CAPMOTOR-2 motor feedback board.
ACD 1.08-C0-2
Compact axis drive, size 1, with a peak current of 8 A at 4 kHz, with CAN board,
with Direct feedback board and with CAPMOTOR-1 motor feedback board.
CAN
C0
Note.
Models with CAN interface (C0) cannot have an encoder simulator board, in other words,
there are no models with references like ACD X.XX- C0 -1-X
AXIS COMPACT DRIVE, ACD
SIZE
Width (mm)
(Models)
CURRENT (A)
Irated / Ipeak
fc: IGBT's switching
frequencies.
for fc = 4 kHz for fc = 8 kHz
15
25
35
50
17.5
25.0
08
4.0 8.0
7.5
15.0
12.5
25.0
35.0
50.0
15
25
35
50
17.5
20.0
08
4.0 8.0
7.5
15.0
9.5
19.0
35.0
40.0
Example:
S
PINDLE
C
OMPACT
D
RIVE
INTERFACE
SCD 2.50-C0-2-B-NR
1
77 mm (15/25)
2
177 mm (35/50/75)
ADDITIONAL
FEEDBACK
FEATURES
B
CAPMOTOR-2
MOTOR
FEEDBACK BOARD
None
CAPMOTOR-1
COMPACT SPINDLE DRIVE, SCD
SIZE
Width mm
(Models)
CURRENT (A)
Imax. in any
duty cycle
fc: IGBT's
switching
frequencies
for fc = 4 kHz
for fc = 8 kHz
A1
Analog I/O
S0
SERCOS
SI
SERCOS and analog I/O
C0
CAN
0
None
1
Encoder simulator
2
Direct feedback
None
Includes external Ballast resistor
NR Does not include external Ballast resistor
BRAKING
RESISTOR
SCD 2.50-C0-2
Compact spindle drive, size 2, with Imax of 50 A at 4 kHz, with CAN board,
with Direct feedback board and with CAPMOTOR-1 motor feedback board.
SCD 2.50-C0-2-B
Compact spindle drive, size 2, with Imax of 50 A at 4 kHz, with CAN board,
with Direct feedback board and with CAPMOTOR-2 motor feedback board.
Note.
Models with CAN interface (C0) cannot have an encoder simulator board, in other words,
there are no models with references like SCD X.XX- C0 -1-X.
Examples.
15
25
35
50
28.0
38.0
10.6
17.5
75
52.0
15
25
35
50
19.5
27.0
10.6
12.5
75
39.0
