SALES REFERENCES
Power supply references
372
DDS
HARDWARE
Ref.1310
12.6 Power supply references
Sales reference of the power supplies, PS-65A.
Sales reference of the power supplies, PS-25B4.
Sales reference of the power supplies, XPS.
Sales reference of the power supplies, RPS.
F. H12/10
Sales reference of the non-regenerative power supply, PS-65A.
F. H12/11
Sales reference of the non-regenerative power supply, PS-25B4.
F. H12/12
Sales reference of the regenerative power supplies, XPS.
F. H12/13
Sales reference of the regenerative regulated power supplies, RPS.
Example:
POWER
(power, rated current)
65A
(65 kW, 120 A)
P
OWER
S
UPPLY (Mains voltage of 400 - 460 V AC)
POWER SUPPLY, PS
PS - 65A
Example:
POWER
(power, rated current)
(25 kW, 45 A)
(24 V DC, 8 A)
P
OWER
S
UPPLY (Mains voltage of 400 - 460 V AC)
POWER SUPPLY, PS
WITH INTEGRATED AUXILIARY 24 V POWER SUPPLY
PS - 25B4
25B4
Example:
POWER
(power, rated current)
25
(25 kW, 45 A)
65
(65 kW, 120 A)
X
-circuit
P
OWER
S
UPPLY (Mains voltage 400-460 V AC)
REGENERATIVE
POWER SUPPLY, XPS
XPS - 25
Example:
POWER
(Power S1/S6,
Current IS1/IS6-40% )
75
(75/97 kW, 120/156 A)
R
EGENERATIVE
P
OWER
S
UPPLY (Mains voltage 400 - 460 V AC)
REGENERATIVE
BOOST POWER SUPPLY, RPS
RPS - 80
45
(45/59 kW, 72/95 A)
20
(20/26 kW, 32/41.6 A)
80 (80/104 kW, 128/166.5 A)
