Fagor DDS User Manual

Sales references
SALES REFERENCES
Cable references
12.
375
DDS
HARDWARE
Ref.1310
Sales reference of the SERCOS interface cable
Sales reference of the CAN interface cable
Sales reference of the connectors for synchronous servo motors.
F. H12/18
Sales reference of the SERCOS interface cable.
F. H12/19
Sales reference of the CAN interface cable.
F. H12/20
Sales reference of the connectors for synchronous servo motors.
Example: SFO - 2
LENGTH (m)
1, 2, 3, 5, 7, 10, 12
SFO S
ERCOS
F
IBER
O
PTIC
FIBER OPTIC LINES
Example: SFO - FLEX - 15
LENGTH (m)
10, 15, 20, 25, 30, 35, 40
SFO - FLEX S
ERCOS
F
IBER
O
PTIC -
F
LEX
FIBER OPTIC LINES
Example: SFO - V - FLEX - 60
LENGTH (m)
40, 50, 60, 75, 100
SFO - V- FLEX S
ERCOS
F
IBER
O
PTIC - V -
F
LEX
FIBER OPTIC LINES
(Polymer core)
(Polymer core)
(Glass core)
Ejemplo: CAN CABLE 5M
LONGITUD (m)
5M, 10M, 15M, 20M, 25M
CAN CABLE
CAN CABLE
Example: CAN CABLE 5M
LENGTH (m)
5M, 10M, 15M, 20M, 25M
CAN CABLE
CAN CABLE
Example: MC 23
POWER CONNECTOR FOR FXM
E0C 12
ENCODER FEEDBACK CONNECTOR (12 pines)
23
(23 A)
MAX. CURRENT
46
(46 A)
AMC
Angled
MC
Vertical
CONNECTORS FOR THE FXM MOTORS
80
(80 A)
Example: MC 61/6
POWER CONNECTOR FOR FKM
E0C 12
ENCODER FEEDBACK CONNECTOR (12 pines)
20/6
(20 A)
MAX. CURRENT
MC
CONNECTORS FOR THE FKM MOTORS
61/6
(61 A)
