Fagor DDS User Manual

379
13
DDS
HARDWARE
Ref.1310
COMPATIBILITY
13.1 Mains voltage
Originally, the drives and power supplies were designed for a mains volt-
age of 380 V AC (50/60 Hz). They all have been now redesigned to work
with mains voltage ranging between 400-460 V AC (50/60 Hz).
Their identification comes on the label that each of these module has.
13.2 Compatibility
The elements ready for mains voltage between 400-460 V AC:
 Drive (version MSC 12A and later).
 Auxiliary power supply APS-24 ( version PF 05A and later ).
 Capacitor module CM 60 (version 01A and later) or CM 1.60 (version
[CAP 00A] [VAR 02A] and later) replacing the previous one.
 Mains filters EMK or MAINS FILTER A compatible with all power
supplies PS, XPS and RPS.
The elements ready for mains voltage between 380 V AC:
 Drive (version MSC 11A and older).
 Auxiliary power supply APS 24 (version PF 04A and older).
 Capacitor module CM 60 (version 00A and later) or CM 1.60 (version
[CAP 00A] [VAR 02A] and later) replacing the previous one.
 Mains filters Power-Pro are not compatible with power supplies PS-
A, PS-25B, XPS and RPS.
F. H1 3/1
Module identification labels. Operating mains voltage.
PS-25MODEL
INPUT
OUTPUT
Fagor Automation,
S.Coop.(Spain)
600 Vdc 45A
3x380 Vac 50/60Hz
PS-25AMODEL
INPUT
OUTPUT
Fagor Automation,
S.Coop.(Spain)
537-650 Vdc 45A
3x400÷460Vac 50/60Hz
AXD 1.15-A1-1MODEL
INPUT
OUTPUT
Fagor Automation,
S.Coop.(Spain)
3x380 Vac 7A 0-800Hz
600-800 Vdc
AXD 1.15-A1-1MODEL
INPUT
OUTPUT
Fagor Automation,
S.Coop.(Spain)
0-800Hz
456-800 Vdc
3x0÷460 Vac 7A
Elements for 380 V AC
Power suppliesDrives
Elements for 400- 460 V AC
