Faller 180725 User Manual

34
General view of product
ANLAGENBAU
EN
Ports Description
»16 VAC« Port for the supply voltage
(16 V alternating voltage)
»Servo 1« to
»Servo 4«
Ports with specific pin assignment, for four servos
»Digital« Port for a digital control unit to program the servo
»Pos A Servo 1« to
»Pos A Servo 4«
Ports for keys that call up the first hold position
in the respective servos (“red keys”)
»Pos B Servo 1« to
»Pos B Servo 4«
Ports for keys that call up the second hold position
in the respective servos (“green keys”)
»0V« Ports for earthing (5x)
Keys Description
»Enter« To confirm inputs
»-« »Minus sign key«
»+« »Plus sign key«
»Prog« To activate the programming mode
LEDs Description
»Prog« Flashes at lower heart rate whenever the Servo
Control is properly connected to the power supply
Lights up whenever the programming mode is acti-
vated
»Servo 1« to
»Servo 4«
Lights up whenever a servo is selected in the pro-
gramming mode
ADVICE: »Servo 1« to »Servo 4« LEDs have in
programming mode further meanings that will be
described in the relevant place.

Faller 180725 Specifications

General

Brand	Faller
Model	180725
Category	Controller
Language	English
