Ref. No. Description Part #
1 Hanger Bracket APG510BL
5 Ceiling Canopy
PG160
¾¾
2 Downrod/Hanger Ball Assembly Containing:
ADR6
¾¾
3 Clevis Pin
4 Hairpin Clip
7 Motor Coupling Cover
MCC
¾¾
Fan Motor Assembly Consisting of:
FP2320 Fan Body
¾¾
8 Housing, Upper
P2370
¾¾
9 Cover, Light Channel (6)
P2330
¾¾
10 Cover, Screw (12) P2335
11 Housing, Motor
P2360
¾¾
12 Screw, Philips Hd. (6) P2365
13 Motor P2380
14 Screw, Philips Hd. (4) P2385
15 Blade, Fan with set screw P2340
16 Housing, Lower
P2351
¾¾
17 Screw, Philips Hd. (6) P2355
18 Bulb, Halogen, BA15D, 120V, 35 watt (6)† LB37
19 Light Kit (set of 6)†
LK23
¾¾
20 Wall Control C9
21 Remote Control C8
27 Receiver REC2320
Support Cable Bag Containing:
HWBSCABLE
22 Ceiling Support Cable
23 Cable Clamp
25 Flat Washer
26 ⅜˝ x 2˝ Lag Bolt
Hardware Bag Containing:
HDWFP2300
6
5/32˝ Threaded Rods (2), 5/32˝ External
Lockwashers (2), Knurled Knobs (2)
24 Wire Connectors (5)
12
Before discarding packaging materials, be certain all parts have been removed
Parts List
¾¾
Insert FINISH CODES (Refer to fan model number located on downrod support)
Model #FP2320**
† Optional - Sold Separately
How To Order Parts
When ordering repair parts, always
give the following information:
• Part Number
• Part Description
• Fan Model Number
Contact your retail store for repair parts.
