How to Assemble Your Ceiling Fan Blades

2. Remove the two set screws and locking nuts in the

downrod support of the motor assembly and retain

for reinstallation in Step 4 of the How to Assemble

Your Ceiling Fan section, Page 8. Remove the six

screws at the top of the motor assembly and retain

them for next step. (Figure 2)

To reduce the risk of personal injury, do not bend the

NOTE: Periodically check blade hardware and

resecure if necessary.

1. Slide blades through slots in motor housing and

attach to the motor hub using the #8-32 serrated

head screws and flat washers. Make sure the screws

securing the blades to the motor hub are tight and are

properly seated. (Figure 1)

blade when installing, balancing the blades or

cleaning the fan. Do not insert foreign objects in

between the rotating blades.

WARNING

HARDWARE USED:

x 9

FLAT WASHERS

#8-32

SERREATED HEAD

SCREWS

Motor Assembly

3. Assemble the upper housing to the motor assembly

using the previously removed screws. (Figure 3)

Figure 2

Figure 1

Set Screws and

Locking Nuts (2)

Upper Housing

Motor

Assembly

Figure 3

#8-32 Serrated Head

Screw with Flat Washer

(3 per assembly)

Motor Assembly

Blade

Fanimation GLIDEAIRE FPD8520 Series User Manual
