ALYA INSTALLATION AND USER’S MANUAL - EN
Edition 2.0 Sept 2018 Pag. 26 di 32
10 TECHCNICAL SPECIFICATION
Dental Light
Dental Light with
Theia Tech
Dental light Head
Power Supply
Without Transformer:
17÷24 V ac ±10%
50/ 60Hz;
24V ac ±10% -50/60 Hz;
24V dc
17÷24Vac±10% -50/60Hz;
22÷33 Vdc
Power supply (with
transformer):
230 Vac±10% 50/60 Hz
240 Vac±10% 50/60 Hz
Not Available
Not Available
Max Power :
26 VA
24Vac: 40 VA
24Vdc: 28 VA
26 VA
Fuses (Version with
transformer included):
2 x T 250mAL 250V
Not Available
Not Available
Reccomended fuses
for installation
without transformer
(not supplied in
charge to installator)
T1.6AL 250V
24Vac: T2AL 250V
24Vdc: T1.25AL250V
17÷24Vac: T1.6AL 250V
22÷33Vdc: T1.25AL 250V
Protection against
electrical hazad
Class II
(final classification of the Protection Class of the Medical System is demanded to
the installator or to the manufacturer)
Classification against
IEC 62471
Class 1- Labelling Exempt
Max illuminance (*)
> 45.000 lux
Typical colour
Temperature(*)
5.000 K
Size of light spot (*)
180 mm x 90 mm
Nature of the radiation
Non ionizing Radiation
Type of radiation
Visible lights
Typical distribution of
illuminance
Typical Spectral
Distribution
(*) Typical optical values subjected to tolerances
Measurement performed at 700 mm distance. Contact Faro for the correct procedure for the measurement.
