- Select the correct number of manual extensions installed by using the "+"
button. If the crane version doesn't allow the installation of all the three
manual extensions, select only the manual extensions allowed though the
"+" button. The selection is valid both for extensions installed on crane
(CRANE) and on hydraulic jib (JIB). Press ENTER to confirm and pass
to the following screen.
F C P 2
- If no load is applied to the hook, bring the outer ram to its stroke end
while lifting. If the ram is already in this condition, perform anyway the
procedure of lifting the ram to be able to pass to the following screen.
E N T E R T O S T A R T
- If the manual extensions are mounted on the hydraulic jib, by pressing
the ENTER button you can get the following screen.
K 1 K 2 K 3 K 4
- Select the outer boom configuration, by using the "+" button:
K1 Outer booms of the crane totally re-entered
K2 Outer booms of the crane totally re-entered and jib extensions
totally extended
K3 Outer booms of the crane totally extended and jib extensions
totally re-entered
K4 Outer booms of the crane and jib extensions totally extended
- Press ENTER to confirm the selected configuration. The following
screen will be displayed.
F C P 3
- Bring the hydraulic jib to its stroke end. If it is already in this position, lift
the ram to be able to pass to the following screen.
E N T E R T O S T A R T
16.7
CONTROLS TO OPERATE
THE CRANE
GR4_5 - EVOLUTION
