10. Control I/O Signal
10. Control I/O Signal
10.1 Signal Cabling (Ezi-SERVO-PR type)
All control I/O signals use connector CN1 as specified below.
1) Input : 「Limit+」, 「Limit-」, 「Origin」 signals are fixed to CN1 No. 1,2,3.
Other signals as like ‘Clear Pos’are assigned to IN1~IN9 terminal blocks.
(3 dedicated input + 9 programmable input = total 12 input pins.)
Ezi-SRERVO-PR : 3 dedicated In + 9 programmable In = 12 Inputs
Ezi-SRERVO-PR-MI : 3 dedicated In + 7 programmable In = 10 Inputs
Ezi-SERVO-PR
CN1 No.
Ezi-SERVO-PR-
MI
CN1 No.
Signal
Name
Function
1
5
Limit+
Positive limit sensor signal
2
6
Limit-
Negative limit sensor signal
3
7
Origin
Origin sensor signal
4
8
IN1
Clear Pos
Position table A0 ~ Position table A7 (PT A0~PT A7)
Position table start execution (PT Start)
Soft Stop(Stop)
Jog+
Jog-
AlarmReset
ServoON
Pause
Origin Search
Teaching
Emergency Stop(E-Stop)
Jump Position Table input 0 ~ Jump Position Table input 2
(JPT IN 0~ JPT IN 2)
Jump Position Table start (JPT Start)
User input 0 ~ User input 8 (User IN 0 ~ User IN 8)
14
9
IN2
15
10
IN3
16
11
IN4
17
12
IN5
5
13
IN6
6
14
IN7
18
None
IN8
19
None
IN9
2) Output : 「COMP」 signal is dedicated to CN1 No.7. Other signals like
Inposition are assigned to OUT1~OUT9 terminal blocks.
Ezi-SRERVO-PR : 1 dedicated Out + 9 programmable Out = 10 Outputs
Ezi-SRERVO-PR-MI : 1 dedicated Out + 1 programmable Out = 2 Outputs
Ezi-SERVO-PR
CN1 No.
Ezi-SERVO-PR-MI
CN1 No.
Signal
Name
Function
7
15
COMP
Specific output signal (Compare Out)
8
16
OUT1
InPosition
Alarm
Moving
Acc/Dec
ACK
END
AlarmBlink
OriginSearchOK
ServoReady
Brake
Position Table output 0 ~ Position Table output 2
(PT OUT 0 ~ PT OUT 2)
User Output 0 ~ User Output 8
9
None
OUT2
10
None
OUT3
11
None
OUT4
12
None
OUT5
13
None
OUT6
20
None
OUT7
21
None
OUT8
22
None
OUT9
