Operation - Driving
02-17-2021 4812325897EN 45
Operation - Driving
Operating the roller
Under no circumstances is the machine to be
operated from the ground. The operator must be
seated inside the machine during all operation.
Set the speed selector (8) to the high operating
position.
Release the parking brake (12).
Check that the steering is working correctly by turning
the steering wheel once to the right and once to the
left while the roller is stationary.
Make sure that the area in front of and behind
the roller is clear.
Carefully move the forward/reverse lever (5) forwards
or backwards, depending on which direction of travel
is required.
Speed increases as the lever is moved away from the
neutral position.
The speed should always be controlled by the
front/rear lever, never changing the engine
speed.
Test the emergency stop by pressing the
relevant button (2) with the machine at low
speed. Prepare for a sudden stop. The motor will
stop and the brakes will be activated.
During operation, check that the warning lamps turn
on.
Fig. Control panel
1. Ignition switch;
2. Emergency stop;
5. Forward-Reverse lever;
8. Speed selector;
12. Parking brake switch.
5
8
12
1
Fig. Control panel
1. Ignition switch;
6. Forward-Reverse lever;
