TST Expanded Startup WU
FEIG ELECTRONIC GmbH Page 17 of 18 WU_erweiterte_ Inbetriebnahme4_GB.doc
P.
[Unit]
Range
Diagnostics
Default
910
0..22 With the aid of this parameter you can show the variables listed below in
the display of the door controller.
The following variables are displayed:
0: The control sequence is displayed (Automatic)
1: [Hz] The current travel speed
2: [A] The current motor current
3: [V] The current motor voltage
4: [A] The current DC-Bus current
5: [V] The current DC-Bus voltage
6: [°C] The power stage temperature in °Celsius
7: [°C] The power stage temperature in °Fahrenheit
8: [s] The run-time of the motor during the last door operation
9: [Increments] The current position
10: [Increments] The position of the reference
11: [Dig] Channel 1 value of the absolute encoder
12: [Dig] Channel 2 value of the absolute encoder
13: [V] Current reference voltage
14: [°C] Temperature inside the housing in °Celsius
15: [°C] Temperature inside the housing in °Fahrenheit
16: Reserved
17: Reserved
18: Rotation speed of the TST PD shaft
)
only with TST PD
19: Reserved
20: Reserved
21: Number of position requisition without answere
22: Number of wrong received signs in TST PD encoder
(activates also the output in P.955)
)
Settings 9 to 15 only have meaning when using an electronic limit
switch.
)
Settings 14 and 15 are only possible when using TST FUS.
0
920
Eb 1
Eb 2
...
Eb 7
Eb 8
Ebcl
Eb -
Display error memory / faults
⇒ Open by pressing STOP key again,
⇒ Scroll with UP / DOWN keys
⇒ Close by pressing STOP key.
⇒ Leave with Cancel "EB-".
• Eb 1 → Error messages 1 (most recent) or. Er--
• Eb 2 → Error messages 2 or Er--
...
• Eb 7 → Error messages 3 or. Er--
• Eb 8 → Error messages 4 or. Er--
• Ebcl → delete complete failure memory
• Eb - → Cancel
(Display noEr: no errors)
Eb 1
925
Display software version
930
[s]
0..120.0
Run-time of motor during last door operation
