Feig Electronic TST WU - Input Configuration Parameters; Safety Edge Parameters

TST Expanded Startup WU
FEIG ELECTRONIC GmbH Page 9 of 18 WU_erweiterte_ Inbetriebnahme4_GB.doc
P.
[Unit]
Range
Safety Edge
Default
460
0..5 Specify Safety edge processing (SL)
(processor must have correctly recognized the terminating resistor value one time)
0. SL inactive (only possible if there is no terminating resistor!)
1. SL active, redundant safety principle, normally open system (short
circuit means tripped, e.g., electrical edge)
2. SL active, SL active, redundant safety principle, normally closed
system (open means tripped)
3. SL active, safety principle is testing in lower end position
(e.g. normally open system)
4. SL active, safety principle is testing in lower end position
(e.g. normally closed system, i.e. pneumatic edge)
5. Dynamic optical System
-1
P.
[Unit]
Range
Inputs
Default
501
0000 ... 1402 Function of input 1
see table 1: Input profiles
502
0000 ... 1402 Function of input 2
see table 1: Input profiles
503
0000 ... 1402 Function of input 3
see table 1: Input profiles
504
0000 ... 1402 Function of input 4
see table 1: Input profiles
505
0000 ... 1402 Function of input 5
see table 1: Input profiles
506
0000 ... 1402 Function of input 6
see table 1: Input profiles
507
0000 ... 1402 Function of input 7
see table 1: Input profiles
508
0000 ... 1402 Function of input 8
see table 1: Input profiles
509
0000 ... 1402 Function of input 9
see table 1: Input profiles
50A
0000 ... 1402 Function of input 10
see table 1: Input profiles
A0F
0000 ... 1402 Function of input 31
see table 1: Input profiles
Only useable with TST SUVEK
