From point 1 to 2 there should be an increase in the distance between the saw blade
and the rip fence.
Test Point Unit type Tolerance
Increase from 1 to 2 of Metric 0.05mm to 0.10mm
(over Ø300mm Saw Blade) Imperial 0.002” to 0.004”
Adju s t m e n t Lin k
Alignments
SR04 Rip Fence Free cut at 90°
