Page. 3
1. General
■ 1-3. Safety precautions
DANGER
● Shut off the power when undertaking construction of the equipment (installation, piping and wiring).
Fire, electric shock or injury may be caused due to a short circuit.
● Do not machine, disassemble or modify the product. An accident, fire, electric shock, electronic part mage or burnout may
be caused. If the product has been modified, we cannot take charge of repair.
WARNING
● Do not use the product when it is faulty. An accident such as electric shock and fire may be caused.
Stop the operation at once and repair the product.
● This machine is not provided with a power switch for the primary power supply.
Be sure to install a power switch at the power supply source.
● Do not leave the product in a subzero environment in the status where sample water or fresh water remains in the sample
water detection tube. The sample water detection tube will be broken by freezing, resulting in a failure.
● Never feed water contaminated with oil or impurities directly into the detection tube in the sensor unit. Since this machine
is a precision equipment, a malfunction or impossibility of measurement may be caused by contaminated detection tube.
● Please use the battery properly without making mistakes in terms of orientation of polarity.
Equipment might break down or be heated which leads to ignition.
CAUTION
●
Never use the operational log memory card of this oil concentration detector (FOCAS-2000) for the existing oil
concentration detector (FOCAS-1800). If used, its data will be lost. We cannot assure and recover any operational log
data lost by the use in the existing oil concentration detector. By the way, FOCAS-2000 can read the operational log
memory card of FOCAS-1800.
2. Specifications
■ 2-1. Product Specification
Application Bilge concentration monitor (bilge wastewater)
Measurement method Optical continuous measurement
Operation method Automatic operation using sample water pressure
Response time 5sec or less, (comply with MEPC107(49))
Power supply / power consumption AC90 ～ 240 V 50 ～ 60 Hz 20 VA or less
Measurement range 30ppm in full scale
Measurement accuracy ±5ppm or less （at 15ppm）
Conditions on samplewater
pressure： 0.03 ～ 0.3MPa flow rate： 0.2 ～ 3 L /min
water temperature： +2 ～ +45°C
Fresh water pressure for washing 0.03 ～ 0.6Mpa
Material measured and identified light oil 10ppm in 100ppm iron oxide solution
Battery for clock and lifetime Lithium battery（CR2450） about 2 years （recommended maker : FDK Energy Co Ltd. Japan）
Service temperature・humidity 0 ～ 50°C, 5 ～ 90％RH, no dew condensation
Bearable vibration 2Hz to 13.2Hz,amplitude ±1.0mm, 13.2Hz to 80Hz, acceleration ±0.7G
Maximum measurement
angle of inclination
Within 22.5°in each direction
Indications and Outputs
Indication of oil concentration：displayed in 24 digits 2 lines. alpha-numeral
Power lanp ：Green LED lighting , Alarm lamp ： Red LED blinks
Alarm1、Alarm2、VALVE Each contact output、REC Analog output
VALVE
(For theree-way valve)
Specification A Contact output: 1 circuit, 1B contact (max. 250 VAC 2 A), supply voltage output
Specification B Contact output: 1 circuit, 1C contact (max. 250 VAC 2 A), supply voltage output
Alarm1 （5～15ppm variable） 1 circuit for contact output, C contact（Max AC250V 2 A） Delay time: 0 to 5 s
Alarm2 （5～15ppm variable） 1 circuit for contact output, C contact（Max AC250V 2 A） Delay time: 0 to 600 s
Terminal specification
/oil alarm operating point
RECout （4-20mA output） DC4-20mA（0-24mA） line resistance less than 750Ω
Operation recording
function
Power-on and -off, output and release time of respective alarms (record memory: 2 Mbit), conformant to MEPC 107(49)
Piping bore
Inlets of sample water and fresh water, and drain port: Outer diameter of F8 or F10 with copper tube ring joints
Cable gland 4 pcs（F10.5 ～ F14.5）
Water-proof grade IP = 54
External dimensions ,
weight
W = 251mm × H = 283.5 mm × D = 122 mm,
Total weight：approx. 4.8 kg （excluding accessories）
