Fema M60-C1 User Manual

FEMA ELECTRÓNICA . Series M . M60-C1
2
1. Panel meter M60-C1
Counter, ratemeter and periodmeter, 96 x 48 mm (1/8 DIN)
Panel meter 96 x 48 mm (1/8 DIN) and 6 digits with 14 mm digit
height, congurable with 5 impulse counter modes (see secon 1.2),
2 ratemeter modes (see secon 1.3) and a 1 periodmeter mode (see
secon 1.4).
Highly congurable, accepts all types of sensors (NPN, PNP, push-
pull, Namur, inducve, pick-up, mechanical, TTL, CMOS, ...) including
quadrature signals (single and bidireconal encoder signals).
Reading from 999999 to -199999 with decimal point, scalable read-
ing with congurable mulplier factor (1 to 999999) and congurable
divider factor (1 to 999999). Includes internal pull-up and pull-down
resistors, congurable trigger levels, detecon by rising or falling
edge, excitaon voltage congurable from 5 Vdc to 18 Vdc.
Opons for output and control with 1, 2 and 3 relays, isolated analog
outputs, communicaons in Modbus RTU, RS-485 ASCII and RS-232.
Special opons with 4 and 6 relay outputs.
Independent alarms congurable as maximum or minimum, with 1
or 2 setpoints per alarm, hysteresis, independent acvaon and de-
acvaon delays and control for inverted relay.
Front protecon IP54 with oponal IP65. Connecons by plug-in
screw terminals. For industrial applicaons.
• ‘Fast access’ menu to selected funcons, accessible with key UP (5)
(see secon 1.19.12)
• Funcon ‘On power up’ for system protecon on rst ‘cold’ start-
up or automac reset (see secon 1.19.14)
• Special ‘FAST’ mode for fast counng applicaons (see secon 1.16)
• Special ‘SLOW’ mode for slow ratemeter applicaons (low frequen-
cy applicaons) (see secon 1.15)
• Direct conguraon for most usual sensor, at the ‘SnSr / Auto’
menu (see secon 1.19.10)
• Funcon ‘Trigger Sense’ helps to detect the correct trigger level
(see secon 1.13)
Mulple display lters, memory for maximum and minimum reading,
password protecon, 5 brightness levels.
Index
1. Panel meter M60-C1 . . . . . . . . . . . . . . . . . . . . . . 2
1.1 How to order . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Impulse counter modes . . . . . . . . . . . . . . . . . . 3
1.3 Ratemeter modes. . . . . . . . . . . . . . . . . . . . . . 3
1.4 Periodmeter mode . . . . . . . . . . . . . . . . . . . . . 3
1.5 Funcons included . . . . . . . . . . . . . . . . . . . . . 3
1.6 Front view . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.7 Power connecons . . . . . . . . . . . . . . . . . . . . . 4
1.8 Sensor conguraon and connecons . . . . . . . . . . 4
1.9 Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.10 Signal connecons . . . . . . . . . . . . . . . . . . . . 4
1.11 Technical specicaons . . . . . . . . . . . . . . . . . . 5
1.12 Mechanical dimensions (mm) . . . . . . . . . . . . . . 5
1.13 Funcon ‘Trigger Sense’ . . . . . . . . . . . . . . . . . 6
1.14 Funcon ‘cycle counter’ . . . . . . . . . . . . . . . . . 6
1.15 ‘SLOW’ mode . . . . . . . . . . . . . . . . . . . . . . . 6
1.16 ‘FAST’ mode . . . . . . . . . . . . . . . . . . . . . . . . 6
1.17 How to operate the menus. . . . . . . . . . . . . . . . 7
1.18 Messages and errors . . . . . . . . . . . . . . . . . . . 7
1.19 Conguraon menu. . . . . . . . . . . . . . . . . . . . 8
1.19.1 Inial set-up . . . . . . . . . . . . . . . . . . . . . . 8
1.19.2 Conguraon for ‘cn.1’ . . . . . . . . . . . . . . . . 8
1.19.3 Conguraon for ‘cnq.2’ . . . . . . . . . . . . . . . 9
1.19.4 Conguraon for ‘cnI.3’ . . . . . . . . . . . . . . . . 9
1.19.5 Conguraon for ‘cnc.4’ . . . . . . . . . . . . . . . 9
1.19.6 Conguraon for ‘cnd.5’ . . . . . . . . . . . . . . . 10
1.19.7 Conguraon for ‘rt.6’ . . . . . . . . . . . . . . . . 10
1.19.8 Conguraon for ‘rtq.7’. . . . . . . . . . . . . . . . 10
1.19.9 Conguraon for ‘Prd.8’ . . . . . . . . . . . . . . . 11
1.19.10 Sensor conguraon. . . . . . . . . . . . . . . . . 11
1.19.11 Alarms . . . . . . . . . . . . . . . . . . . . . . . . 13
1.19.12 Fast access . . . . . . . . . . . . . . . . . . . . . . 14
1.19.13 Super fast access . . . . . . . . . . . . . . . . . . . 14
1.19.14 Menu ‘On Power Up’ . . . . . . . . . . . . . . . . 14
1.19.15 Menu ‘Key LE’ . . . . . . . . . . . . . . . . . . . . 15
1.19.16 Menus ‘Overrange / underrange’. . . . . . . . . . 15
1.19.17 Le zeros . . . . . . . . . . . . . . . . . . . . . . .15
1.19.18 Funcon ‘Password’ . . . . . . . . . . . . . . . . .15
1.19.19 Factory reset . . . . . . . . . . . . . . . . . . . . .15
1.19.20 Firmware version. . . . . . . . . . . . . . . . . . . 15
1.19.21 Brightness . . . . . . . . . . . . . . . . . . . . . . 15
1.19.22 Access to oponal modules . . . . . . . . . . . . . 15
1.20 Full conguraon menu . . . . . . . . . . . . . . . . . 16
1.21 Factory conguraon . . . . . . . . . . . . . . . . . . .19
1.22 To access the instrument . . . . . . . . . . . . . . . . .20
1.23 Modular system . . . . . . . . . . . . . . . . . . . . . .20
1.24 Precauons on installaon . . . . . . . . . . . . . . . .21
1.25 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1.26 CE declaraon of conformity . . . . . . . . . . . . . . . 21
2. Output and control modules . . . . . . . . . . . . . . . . . 22
2.1 Module R1. . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.2 Module AO . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.3 Module RTU. . . . . . . . . . . . . . . . . . . . . . . . . 23
2.4 Module S4. . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.5 Module S2. . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.6 Modules R2, R4, R6. . . . . . . . . . . . . . . . . . . . . 24
3. Other opons . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.1 Opon NBT . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.2 Opon 65 . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.3 Opon G. . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .27
4.1 THM benchtop housing . . . . . . . . . . . . . . . . . . 27
4.2 Adapter KA96 . . . . . . . . . . . . . . . . . . . . . . . .27
4.3 Adapter DRA-M . . . . . . . . . . . . . . . . . . . . . . . 27
4.4 Protector KIP . . . . . . . . . . . . . . . . . . . . . . . . 27
