FEMA ELECTRÓNICA . Series M . M60-C1
4
Buon ‘LE’
Earth connecon - Although a
terminal is provided for earth
connecon, this connecon is
oponal. The instrument does
not need earth connecon for
correct operaon nor for com-
pliance with the security regu-
laons.
~
~
+
-
8 9 0
Fuse - To comply with security regulaon 61010-1, add to the power
line a protecon fuse acng as disconnecon element, easily acces-
sible to the operator and idened as a protecon device.
Power ‘H’ fuse 250 mA me lag
Power ‘L fuse 400 mA me lag
1.7 Power connecons
1.6 Front view
Buon ‘UP’
Logo
Alarms
Units
Buon ‘SQ’
‘Conguraon menu’
(see secon 1.19)
‘Fast access‘
(see secon 1.19.12)
1.8 Sensor conguraon and connecons
Signal
(see secon 3.2)
Opon 1 Opon 2Opon 3
Power
(see secon 1.7)
12345 890
Detail of the plug-in screw terminals provided with
the instrument. The instrument is provided with all
terminals needed, both male and female.
1.9 Rear view
1.10 Signal connecons
Selecng one of the sensors listed at the
SnSrmenu entry, will congure the sen-
sor parameters to the values indicated in
the table.
The table also indicates the typical con-
necons for each type of sensor. Param-
eters can be manually modied.
Connecons are indicated for a single sen-
sor connected to the channel A. For two
sensors (for inhibion control, quadrature
signal, etc) apply the same connecon cri-
teria also to channel B.
Note : indicated values are typical values.
Check the correct specicaons with your
sensor datasheet and adapt the required
conguraon and connecons as needed.
Sensor Connecons Pulls Vexc. Anrrebound
lter
Trigger
Mechanical contact 0 V channel A pull-up no 100 mSec. 2,5 Vdc
Namur channel A Vexc pull-down 9 Vdc no 3,0 Vdc
NPN 2 wires 0 V channel A pull-up 18 Vdc no 2,5 Vdc
NPN 3 wires 0 V channel A Vexc pull-up 18 Vdc no 2,5 Vdc
PNP 2 wires 0 V channel A pull-down 18 Vdc no 2,5 Vdc
PNP 3 wires 0 V channel A Vexc pull-down 18 Vdc no 2,5 Vdc
Push-pull 0 V channel A Vexc no 18 Vdc no 2,5 Vdc
TTL
CMOS
Pick-up
0 V channel A no 5 Vdc no 2,5 Vdc
AC<30 Vp
Inducve
0 V channel A no no no 0 Vdc
Table 2 - Conguraon and connecons for dierent types of sensors.
Front reset
(see secon 1.19.15)
Vexc.
12345
Canal B
Reset
0 V
Canal A
Units
