Pag 39
MDS DIRECT
MDS DIRECT
Rear view details of MDS DIRECT Audio-Video panels:
City Amplifier:
1. Outdoor Panel Volume.
2. Telephone/Monitor Volume
3. Setup Bridges.
Display Module:
4. Telecamera and switcher connector.
5. Amplifier connector.
6. Keypad connector.
7. Input Terminals.
8. Output Terminals.
Telecamera:
9. Adjust Pan &Tilt.
10. Test Connector.
Keypad Module:
11. Rear view.
VERY IMPORTANT NOTES:
9 This Installer’s Manual indicates all the steps and precautions to be taken for the correct installation
of the equipment, leaving it in operational conditions (making calls, open door, etc.).
9 Functions associated with access control will only be operative after the intervention of the system
administrator (Section II Administrator Manual included along with this documentation).
9 Installation scheme diagrams are available upon request, our Technical Books:
- MDS Technical Book (Code 94726).
- MDS-ADS Technical Book (Code 97002).
Both also available in the Technical Area section of our website: www.fermax.com
