High Voltage Power Supply
Type: CARRERA
- Connect the filament power supply to the emergency
switching system of the whole equipment.
Please, note that before the connection of the high-voltage
power supply unit the complete cabling of the vacuum system,
the electron beam vaporizer, the filament power supply and the
Genius control unit must be installed.
Wiring diagram (with an electron beam vaporizer) and the
GENIUS control unit.
.
On special versions the wiring diagram attached in the
Appendix is valid in these case of these designs.
If the Genius control unit is used the wiring diagram shown in
this operation manual is valid.
The wiring diagram contains all connections.
The plugs are marked with X...; you will find this marking on the
devices as well. The marking of the cables is 95 .. .. At the same
time these are part numbers for ordering spare parts.
