Version 1.3_15 EN
36
High Voltage Power Supply
Type: CARRERA
Earthing line
- Connect the earthing contact X300 of the high-voltage power
supply unit to the earthing point of the vacuum chamber.
- For this purpose use a cable with cable lugs, green/yellow wire
sheathing and the cross-section of 16 mm².
Control Line
The Y-control cable represents the connection of the high voltage
power supply and the genius control unit.
- Connect the high voltage power supply the Genius control unit
(Analog: connector X302, Digital: plug X303).
NOTICE
The Y-control cable is part of the scope of delivery of the
Genius controller .
NOTICE
If you have bought the high-voltage power supply unit without a
control unit, use common connectors and connect them in
accordance with connector assignment
Pin assignment of the interfaces
Digital interface connector X303: (15-pole Sub-D connector)
Digital Input:
PIN1
High Voltage ON
in
(15-30V DC
PIN2
High Voltage Status
(-)
max. 20 mA Input current)
PIN 3
PIN 4
Reset
Reset
in
(-)
Digital Outputs:
PIN 5
High Voltage ON
out
(15-30V DC
PIN 6
Hochspannung vorhanden
(+)
max. 20 mA Output current)
PIN 7
PIN 8
Unit O.K.
Unit O.K.
out
(+)
PIN 9
PIN 10
Current limt exeeded
Current limt exeeded
out
(+)
PIN 11
PIN 12
ARC-Error
ARC- Error
out
(+)
PIN 13
PIN 14
Overtemperature
Overtemperature
out
(+)
