Filtration Learning System
© Festo Didactic 696684
17
6 Technical data
6.1 General data
Parameter Value
Operating pressure (compressed air) 600 kPa (6 bar)
Max. operating pressure in piping (water) 50 kPa (0.5 bar)
Operating voltage 24 V DC, 4 A, ≤ 100 W output power, SELV/PELV limited
power supply (LPS)
Digital inputs/outputs
Inputs: 4
Outputs: 4
Analog inputs/outputs
Inputs: 1
Outputs: 1
Max. 24 V DC
Max. 0.5 A per output
Max. 4 A total
Signal range of the final control
element
Proportional pressure regulator
Pressure 0…2 bar
Voltage 0...10 V
Working range of the pressure system 0...2 bar
Measuring range of the pressure sensor 0...10 bar
Signal of the sensor of the pressure system Voltage 0...10 V
Electrical connection 24-pin IEEE-488 socket (SysLink)
15-pin ISO 4903 socket (Sub-D)
Pneumatic connection Plastic tubing with 6 mm outside diameter
Compressed air consumption at 600 kPa (continuous cycle) 10 l/min
Process connections Flexible piping system DN10 (∅
a
15mm)
Volumetric flow rate of the pump ~ 10 l/min
Tank volume, waste water tank and process water tank Max. 10 l
Dimensions of the station 700 mm x 700 mm x 1030 mm
Dimensions of the profile plate 700 mm x 700 mm x 32 mm
Weight, station 70 kg
Subject to change
