Filtration Learning System Commissioning
© Festo Didactic 696684
49
Siemens TP700 Comfort
For example, use a control console with Siemens TP700 Comfort.
Programming software: Siemens STEP7 version 14 (SP1) or higher
1. Connect the PC and HMI with the network cable
2. Switch on the power supply
3. Start the TIA-Portal development environment
4. In the de-archived project (see above), select the corresponding sub-project of the station “tpBottling”.
5. Load the project into the operator unit. Help can be found at Getting started
.
11.5.5 Starting the sequence
1. Check the power supply and compressed air supply.
2. Empty/Fill the station as described in “chapter 11.2 Filling and emptying”.
3. Select the automatic operating mode with/without downstream station.
4. Select a recipe in the process type.
5. Press the Start button.
6. The station starts the sequence.
Notes
• The sequence can be stopped at any time by pressing the emergency stop button or
the STOP button.
