Setup Filtration Learning System
24 © Festo Didactic 696684
8.2.1 Main components
The following components are included in the scope of delivery. The data sheets can be found in numerical
order as a PDF data sheet collection.
Datasheets Designation Order no Quantity
8001221 Pressure sensor 0-10 bar (2) 8001221 1
557771 Proportional pressure regulator: 0-2 bar 557771 1
170712 Pump (12) 170712 2
739208 Stirrer (8) 739208 1
689201 Tank, square (9) + (10) 548595 2
690588 Sensor, capacitive 549824 4
691282 Float switch, lateral installation 691282 2
696660 Filter 544303 1
691306 Gate valve with pneumatic linear drive and position feedback signals (6) 691306 1
690603 Butterfly valve with pneumatic actuator and sensor box (5) 1
691233 3-way ball valve with pneumatic actuator (11) 1
170704 Check valve 170704 2
I/O board (7) 1
8025736 I/O terminal 8025736 1
8025737 Analog terminal 8025737 1
541150 Motor controller 541150 2
150768 Starting current limiter 150768 1
BEEL0426 H-rail relay, 2 changeover contacts 268327 3
17070x Pipe, straight, pipe section of 800 mm 304518 3 m
17070x L-plug connector 170701 10
17070x T-plug connector 170702 2
17070x Hand lever valve 170703 4
17070x Blanking plug 170705 4
17070x Push-in bracket 90° 690590 8
159410 Aluminum profile plate 700 x 700 159410 1
540691 Start-up valve with filter control valve 540691 1
