C Festo Parameter Channel (FPC)
162 Festo – GDCP-CMMO-ST-LK-C-HP-EN – 2017-05b – English
C.4.7 Error codes
In parameter file transmission, errors are reported in the FPCS or in the package ID of the EFPC,
depending on the type of error.
Error type 1 – The error is displayed in the FPCS (FPCS = xxxx0111)
This variant exists for all FPC variants, including all EFPC types. In the user data, the error code is repor
ted according to the following table:
Error code
Error
17 0x11 Job cannot be carried out in the operating status.
A parameter file transmission is not possible in the current operating
status or configuration (e.g. no EFPC parameterised).
101 0x65 Festo: ReqID is not supported.
Tab. C.10 Error codes in the parameter file transmission – error type 1
Error type 2 – Error is displayed in the control bytes (package ID = 011xxxxx)
Byte 3 includes error codes that the motor controller sends to the controller. If the controller sends an
error or the motor controller error results in interruption of parameter file transmission, this is stored as
information in the diagnostic memory of the motor controller. The controller does not send an error
number in the user data. The motor controller answers the controller with the error status without an
error text in the user data.
Error code Error
0 0x00 Error message from the controller
1 0x01 Incorrect sequence of the received packages (sequence number)
2 0x02 Timeout between 2 packages
3 0x03 Formatting of the telegram invalid
4 0x04 Incorrect command sequence, e.g. renewed start without a stop in
between
5 0x05 Error when reading (length of the parameter file invalid or incorrect
status of transmission)
6 0x06 Error in writing the parameter file
7 0x07 Dataset received or sent does not agree with what was expected
8 0x08 Error in accessing the parameter file, e.g. no master control
9 0x09 Timeout in accessing the parameter file, e.g. error is still present and
must be acknowledged
Tab. C.11 Error codes in the parameter file transmission – error type 2
The errors differ regarding the effect on transmission è Tab. C.12:
