3 Mechanical installation
Festo – GDCP-CMMP-M0-HW-EN – 1511c – English 21
Fig. 3.1 Motor controller CMMP-AS-...-M0: Mounting plate
CMMP-AS-... H1 L1 L2 L3 L4 L5 L6 B1 B2 B3 D1 D2
-3A-M0 [mm] 207 248 202 281 12.5 19 10.5 66 61 30.7 10 5.5
-11A-P3-M0 [mm] 247 297 252 330 12.5 19 10.5 79 75 37.5 10 5.5
Tab. 3.1 Motor controller CMMP-AS-...-M0: Dimensions table
