PLEASE NOTE
For fitting the modules onto a hat rail you will require
fastening kit CP-TS-HS35. This kit contains 2 fasten-
ings, 2 M4x12 screws and 2 washers.
In order to fit the modules onto a hat rail, proceed as
follows:
Fitting onto a
hat rail
1. Make sure that the fastening surface can support
the weight of the module.
2. Fit a hat rail (support rail EN 50022 - 35x15; width
35 mm, height 15 mm).
3. Fasten the hat rail at least every 100 mm to the sup-
port surface.
4. Let both fastenings on the hat rail snap into the
module (see Fig. 1/3).
5. Screw the housing on to the fastening with the
screws supplied as shown in the diagram below.
6. Tighten the screws. The fastening and the housing
will then be clamped tight on the hat rail.
1. Input module type CP-E16...-M...
1-6 CP-E16...-M... 9611A
