Circuitry examples of CP-A08-M12 (PNP outputs)
Pin assignment
Circuitry examples
1
2
3
Example 1
Example 2
Not permitted
A = output
n.c. = not connected
Fig. 2/5: Circuitry examples of output module CP-A08-M12
Pin 1: n.c.
Pin 4: Ax+1
Pin 3: 0 V
Pin 2: n.c.
2
3
1
2. Output module type CP-A08...-M12
2-8 CP-A08...-M12 9611A
