Pin assignment of the actuator connections
(NPN outputs)
*) Consuming device/load must be supplied via this 24 V connection
n.c. = not connected
A = Output
Fig. 2/6: Pin assignment of output module CP-A08N-M12
1
0
3
2
OUT 7
6 4
5
IN
13
2 0
Ax+1
Ax
Pin 2: PE
Pin 2: PE
Pin 3: n.c.
Pin 3: n.c.
Pin 4: Ax
Pin 4: Ax+1
Pin 1: 24 V
*)
Pin 1: 24 V
*)
2. Output module type CP-A08...-M12
CP-A08...-M12 9611A 2-9
