Internal layout of CP-A08N-M12 (NPN outputs)
1
2
3
4
Load voltage connection
PLC/I-PC Ax+1 (e.g. via field bus)
Electrical isolation
Not connected
5
6
7
8
Yellow LED
Green LED
Diagnosis • short circuit, overload
• load voltage failure
Actuator connection
Fig 2/7: Internal layout of output module CP-A08N-M12
Pin 3
Pin 4
Pin 2
Pin 1
Pin 3
Pin 4
Pin 1
Pin 2
PE
0 V
1
2
3
PE
4
7
5
6
8
24 V ± 25%
2. Output module type CP-A08...-M12
2-10 CP-A08...-M12 9611A
