1. Installation
1-26
Festo P.BE-FB14-EN en 1411d English
With the Festo fieldbus plug, you can implement a T-adapter
(è Fig. 1/6).
ÓÓ
ÓÓ
231
4
5
6
1 Fieldbus
2 Voltage supply
3 Screening
4 Branch line
5 T-adapter (T-tap)
6 Fieldbus plug with T-adapter function
Fig. 1/6: Structure of the bus interface and example of connection
