Festo CPX-FB14 - Example 3: Node Guard Monitoring

2. Commissioning
2-31
Festo P.BE-FB14-EN en 1411d English
Configuration and addressing example 2
8DI 8DI 4DO 8DI 2AI8DO
O0…O7
I0…I7 I8…I15 I16…I23
O8…O15 O16…O23
T-PDO 2
R-PDO 1
2AO
AI0 AI1
AO1AO0
T-PDO 1
R-PDO 2
8O
12345
Module no.: 76
Fig. 2/4: Assignment of the PDOs on a CPX terminal with digital and analogue I/O
modules, VTSA pneumatics (DIL switch setting 8O) and not-activated
diagnostic functions (standard assignment without mapping, configuration
è Tab. 2/36)
